TP-Link Omada VPN Router with 10G Ports (er8411)
(No reviews yet)
Write a Review
- SKU:
- 19734207
- MPN:
- er8411
- Availability:
- Usually ships the same or next business day. In stock at our CA, IL warehouses.
- Shipping:
- Calculated at Checkout
- Stock Update:
- 12/20/2024 05:08:34 PM PST
- Stock Update:
- 12/20/2024 05:08:34 PM PST
Description
This item is brand-new, factory sealed.
Omada VPN Router with 10G PortsIntegrated into Omada SDN: Zero-Touch Provisioning (ZTP)*3, Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
Two 10GE SFP+ Ports: 1 WAN and 1 WAN/LAN 10GE SFP+ ports provide high-bandwidth aggregation connectivity.
Up to 10 WAN Ports: Fiber and RJ45 WAN ports with load balance raise the utilization rate of multi-line broadband 1.
Highly Secure VPN: Enterprise-standard SSL/ IPSec / PPTP / L2TP VPN & OpenVPN / L2TP over IPSec VPN are ideal for use across multiple branches and for WFH.
Abundant Security Features: Powerful Firewall, DoS defense, IP/MAC/URL filtering, and IP-MAC Binding, and One-Click ALG Activation provide world-class security.
Note
1. At least one WAN/LAN port needs to function as a LAN port.
3. Zero-Touch Provisioning requires the use of Omada Cloud-Based Controller. Please go to Omada Cloud-Based Controller Product List to find all the models supported by Omada Cloud-Based Controller. HARDWARE FEATURES
Interface
2x 10GE SFP+ Ports (1 WAN, 1 WAN/LAN)
1x 1GE SFP WAN/LAN Ports
8x 1GE RJ45 WAN/LAN Ports
1x RJ45 Console Ports
2x USB Ports (Connecting 4G/3G Modem as WAN Backup)
Button
Reset Button
Power Supply
Redundant Dual Power Supplies (100 to 240 VAC, 50/60 Hz)
Flash
4MB SPI NOR + 256 MB NAND
DRAM
4 GB DDR4
LED
PWR, SYS, WAN, LAN, USB, FAN
Max Power Consumption
26.36 W (with USB 3.0 connected)
19.12 W (without USB 3.0 connected) PERFORMANCE
Concurrent Session
2,300,000 New Sessions /Second
20,000 NAT (Static IP)
Upload: 9445.82 Mbps
Download: 9449.26 Mbps NAT(DHCP)
Upload: 9426.83 Mbps
Download: 9426.20 Mbps NAT(PPPoE)
Upload: 9413.96 Mbps
Download: 9102.01 Mbps NAT (L2TP)
Upload: 4230.62 Mbps
Download: 4169.53 Mbps NAT (PPTP)
Upload: 3933.86 Mbps
Download: 3821.97 Mbps 64 Byte Packet Forwarding Rate
Upload: 1080 Mbps
Download: 1030 Mbps IPsec VPN Throughput
SHA1-AES256: 2140.45 Mbps
SHA2-AES256: 2080.20 Mbps OpenVPN
1665.64 Mbps L2TP VPN Throughput
Unencrypted: 5013.50 Mbps
Encrypted: 2274.74 Mbps SSL VPN Throughput
1511.10 Mbps BASIC FUNCTIONS
WAN Connection Type
Static/Dynamic IP
PPPoE
PPTP
L2TP
6to4 Tunnel
Pass-Through
Mobile Broadband: 4G/3G modem for backup via USB port
MAC Clone
Modify WAN/LAN MAC Address4
DHCP
DHCP Server/Client
DHCP Address Reservation
Multi-net DHCP
Multi-IP Interfaces
IPv6
WAN Connection
VLAN
802.1Q VLAN
IPTV
IGMP v2/v3 Proxy ADVANCED FUNCTIONS
ACL
IP/Port/Protocol/Domain Name Filtering Advanced Routing
Static Routing
Policy Routing
Bandwidth Control
IP/Port-based Bandwidth Control
Guarantee and Limited Bandwidth
Load Balance
Intelligent Load Balance
Application Optimized Routing
Link Backup (Timing5, Failover)
Online Detection
NAT
One-to-One NAT5
Multi-Net NAT
Virtual Server
Port Triggering5
NAT-DMZ
FTP/H.323/SIP/IPSec/PPTP ALG
UPnP
Security
SPI Firewall
VPN Passthrough
FTP/H.323/PPTP/SIP/IPsec ALG
DoS Defence, Ping of Death
Local Management
Session Limit
IP-based Session Limit VPN
SSL VPN
SSL VPN Server
SSL VPN Client
500 OpenVPN Tunnels
IPsec VPN
300 IPSec VPN Tunnels
LAN-to-LAN, Client-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, SHA1, SHA2, AES128, AES192, AES256 Encryption Algorithm
IKE v1/v2
MD5, SHA1 Authentication Algorithm
NAT Traversal (NAT-T)
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)
PPTP VPN
PPTP VPN Server
PPTP VPN Client (32)6
300 Tunnels (Shared with L2TP)
PPTP with MPPE Encryption
L2TP VPN
L2TP VPN Server
L2TP VPN Client (32)6
300 Tunnels (Shared with PPTP)
L2TP over IPSec
OpenVPN
OpenVPN Server
OpenVPN Client (10)6
110 OpenVPN Tunnels SECURITY
Filtering
WEB Group Filtering5
URL Filtering
Web Security5
ARP Inspection
Sending GARP Packets5
ARP Scanning5
IP-MAC Binding5
Attack Defense
TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN
Access Control
Source/Destination IP Based Access Control AUTHENTICATION
Web Authentication
No Authentication
Simple Password2
HotspotLocal User / Voucher2 / SMS2 / Radius2
External Radius Sever
External Portal Sever2
Facebook Check-In2
Instagram Follow2 MANAGEMENT
Omada App
Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Features
Package Contents:
Yes
Restriction of Hazardous Substances (RoHS)
- Omada VPN Router with 10G Ports
- Power Cord
- Rack-Mount Kit
- Quick Installation Guide
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Specs
| Power Description | |
| Redundant Power Supply Supported | Yes |
| Power Source | Power Supply |
| Power Consumption | 19.12 W |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 1.7" |
| Width | 17.3" |
| Depth | 8.7" |
| Warranty | |
| Limited Warranty | 5 Year |
| Interfaces/Ports | |
| Number of WAN Ports | 8 |
| Total Number of Ports | 8 |
| Powerline | No |
| Management Port | Yes |
| USB Standard | USB 3.0 |
| I/O Expansions | |
| Total Number of Expansion Slots | 3.0 |
| General Information | |
| Brand Name | TP-Link |
| Manufacturer Website Address | http://www.tp-link.com/us |
| Marketing Information | Future-Proof Your Business with 10G Enterprise Connectivity Omada VPN Router with 10G Ports ER8411 Centralized Cloud Management Seamless integration into the Omada SDN platform Up to 10 WAN Ports Multi-WAN Load Balance raises the utilization rate of multi-line broadband High-Security VPN Enterprise-standard SSL / IPSec / PPTP / L2TP VPN & OpenVPN / L2TP over IPSec VPN Quad-Core 2.2 GHz CPU Enterprise-level hardware design provides maximum performance Two USB 3.0 Ports Available 4G/3G Modem connection for LTE WAN backup Enhanced Security Powerful Firewall, DoS defense, IP/MAC/URL/ Keyword filtering Two 10GE SFP+ Ports High-bandwidth aggregation with 1? WAN and 1? WAN/LAN ports High-Capacity Performance Supports up to 2,300,000 concurrent sessions Dual Redundant Power Supplies Carrier-class reliability for enterprise networking High-Capacity Performance with Quad-Core 2.2 GHz CPU Manage your entire business network with the right amount of processing power. Dual redundant power supplies further ensure carrier-class reliability for enterprise networking. Maximize the 10G Broadband with Omada Enterprise Gateway Maximized 10G Broadband with the Omada Enterprise Gateway Build your lightning-fast network with Omada ER8411 - an enterprise VPN router with 10G ports. It surpasses the need for high-speed, reliable, and safe enterprise networks, ideal for large-scale deployments such as offices, schools, and hotels. Easily Build a Whole 10G Enterprise Network | 10? WAN Ports & One USB WAN for Mobile Broadband Up to 10? WAN SFP+, SFP, and RJ45 ports allow the router to support various internet access requirements. Multi-WAN Load Balancing distributes data streams according to the bandwidth proportion of every WAN port to raise the utilization rate of multi-line broadband. Connect a 4G/3G modem to one of the USB 3.0 ports for LTE WAN backup. High-Security and High-Performance VPN ER8411 supports pass-through traffic and multiple VPN protocols, including SSL, IPSec, PPTP, and L2TP in Client/Server mode. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment. The router also features built-in VPN engine hardware, allowing support and management of hundreds of IPSec, PPTP, L2TP, SSL VPN, and OpenVPN Tunnels. Robust Security Features | Powerful Firewall Advanced firewall policies protect your network and data. Convenient VLAN Support Create virtual network segments for enhanced security and simplified network management. |
| Product Type | Router |
| Product Name | Omada VPN Router with 10G Ports |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | ER8411 |
| Product Model | ER8411 |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology |
|
